SOLVED: Exception calling “StartWorkflow” with “X” argument(s)

Trying to start a SharePoint workflow using PowerShell and I couldn’t get past this error:

Exception calling “StartWorkflow” with “4” argument(s): “Object reference not set to an instance of an object.”

or

Exception calling “StartWorkflow” with “3” argument(s): “Object reference not set to an instance of an object.”



NO clue if there is a bug in my farm, but the script below works.  Ended up having to re-get the item when running the workflow. $manager.StartWorkflow($list.GetItemById($item.ID),$assoc,$data,$true)

$web = Get-SPWeb "http://rootSiteCollection.com"
$list = $web.Lists["Shared Documents"]

$assoc = $list.WorkFlowAssociations |Where { $_.Name -eq "tacoWF"}
$data = $assoc.AssociationData
$manager = $web.Site.WorkflowManager

$sQuery = New-Object Microsoft.SharePoint.SPQuery

#Get all items with an ID greater than 5
$caml = '<Where><Gt><FieldRef Name="ID" /><Value Type="Counter">5</Value></Gt></Where>'
$sQuery.Query = $caml
$fItems = $list.GetItems($sQuery)

Foreach($item in $fItems)
{
	$manager.StartWorkflow($list.GetItemById($item.ID),$assoc,$data,$true)
}



SharePoint OfficialFile.asmx NotFound

When using the SubmitFile method of the OfficialFile.asmx service, I was returned this value: NotFound

NotFound

Simple fix was to add my account to the Records Center Web Service Submitters group on the site.

Healthy return message from the service:
“Successhttp://site/_layouts/DocIdRedir.aspx?ID=AHVCF7U4ZST3-8-55&hintUrl=myLibTestA%2ftest1_2F4IOO.docx”

Good example on how to upload load files to the Drop Off Library using OfficialFile.asmx service.
https://msdn.microsoft.com/en-us/library/office/gg650433(v=office.14).aspx

The post outlines setting up routing rules and submitting files.

More info on the web service can be found here:
http://download.microsoft.com/download/8/5/8/858F2155-D48D-4C68-9205-29460FD7698F/[MS-OFFICIALFILE].pdf

Value                                                   Meaning
Success                                                    The operation is successful.
MoreInformation                                  The operation is successful but further action is needed.
InvalidRouterConfiguration               The operation failed because the repository was not configured for routing.
InvalidArgument                                   The operation failed because of an invalid argument.
InvalidUser                                             The operation failed because of an invalid user.
NotFound                                                The operation failed because the user was not authorized to submit files.
FileRejected                                            The operation failed because of a rejected file.
UnknownError                                       The operation failed because of an unknown error.

SharePoint 2016 new-spconfigurationdatabase the user does not exist

When installing SharePoint 2016 from PowerShell, make sure you use the machineName\userName when prompted.



Example:

New-SPConfigurationDatabase –DatabaseName SharePoint_Config –DatabaseServer machineName\sqlInstance –AdministrationContentDatabaseName SharePoint_Content –Passphrase (ConvertTo-SecureString BigTaco@12345 –AsPlaintext –Force) –FarmCredentials (Get-Credential) -localserverrole SingleServerFarm

A login prompt will appear.

for the username: enter your machine name \ username (WIN-SP16\spUser).

Error I received when I tried to use spUser without the machine name.

new-spconfigurationdatabase the user does not exist

Are SharePoint Designer Workflows Using Custom Features or Solutions (iLoveSharePoint)

Needed to audit a farm to see if a CodePlex solution was being used in SharePoint Designer workflows.  In my case, I needed to see where the iLove SharePoint  solution was being used. The script below is only targeted at one web and is looking for word “ILoveSharePoint” in the XML.




if ((Get-PSSnapin "Microsoft.SharePoint.PowerShell" -ErrorAction SilentlyContinue) -eq $null)
{
	Add-PSSnapin "Microsoft.SharePoint.PowerShell"
}

[Microsoft.SharePoint.SPSecurity]::RunWithElevatedPrivileges(
	{

		$resultsarray =@()
		#output file name
		$fileName = "C:\ilsp-" + $(Get-Date -Format "yyyyMMddHHmmss") + ".csv"
		#name of the feature we are looking for
		$wFeatureName = "ILoveSharePoint"

		Function GetFiles($folder)
 {
			foreach($file in $folder.Files)
			{
				if($file.Name.Split('.')[-1] -eq "xoml")
				{
					$web2 = Get-SPWeb $file.Web.Url
					$wFile = $web2.GetFileOrFolderObject($web2.URL +"/"+ $file.URL)

					if ($wFile.Exists -eq "True")
					{
						$wXml = (New-Object System.Text.UTF8Encoding).GetString($wFile.OpenBinary());
						$nsDetail = $wXml.OuterXml.ToLower()

						$wFeatureName = $wFeatureName.ToLower()

						if($nsDetail -Like "*$wFeatureName*")
						{
							$outFolder = $folder -replace "Workflows/",""

							$outObject = new-object PSObject
							$outObject | add-member -membertype NoteProperty -name "URL" -Value $web2.Url
							$outObject | add-member -membertype NoteProperty -name "Workflow" -Value $outFolder
							$outObject | add-member -membertype NoteProperty -name "Created By" -Value $wFile.Author
							$outObject | add-member -membertype NoteProperty -name "Created Date" -Value $wFile.TimeCreated
							$outObject | add-member -membertype NoteProperty -name "Modified By" -Value $wFile.ModifiedBy
							$outObject | add-member -membertype NoteProperty -name "Modified Date" -Value $wFile.TimeLastModified

							$global:resultsarray += $outObject
						}
					}
				}
			}

			# Use recursion to loop through all subfolders.
			foreach ($subFolder in $folder.SubFolders)
			{
				GetFiles($Subfolder)
			}
		}

		$WebApplications = Get-SPWebApplication

		foreach($webApp in $WebApplications)
		{
			foreach($site in $webApp.Sites)
			{
				if ((Get-SPSite $site.url -ErrorAction SilentlyContinue) -ne $null)
				{
					foreach($web in $site.AllWebs)
					{
						if ((Get-SPWeb $web.url -ErrorAction SilentlyContinue) -ne $null)
						{
							$list1 = $web.Lists.TryGetList("Workflows")
							if($list1 -ne $null)
							{
								GetFiles($list1.RootFolder)
							}
						}
					}
				}
			}
		}

		#output file
		$resultsarray | Export-csv $fileName -notypeinformation

	}
)

The workflow could not update the item, possibly because one or more columns for the item require a different type of information.

SharePoint Designer workflow error:
The workflow could not update the item, possibly because one or more columns for the item require a different type of information.

If you look at the workflow history nothing of value is there to clue you into what field is broken.

To track down what field is broken, I added a Pause action to my Step. Then I added a Log message before each action. Doing this helped track down the broken field.

The workflow could not update the item

Once you get the workflow working again, remember to clean up the added Log actions.

In my case, the workflow was trying to update a Person / Group field with an employee that no longer worked at the company.

System.IO.FileNotFoundException: The web application at could not be found

Online, I found a lot of different solutions to the error but none of them would solve my issue. I had written a console app that reads data from a SharePoint library, then processes the data. The process is started using a scheduled task and runs under the context of a service account. The account had contribute permissions on the library and read access to the site.

The solution:
On the SharePoint Config and Content database(s), grant the account SharePoint_Shell_Access.

After doing this, I noticed this message in the app’s call stack:

 executed on connection "Data Source=SPDevDB;Initial Catalog=SP2010_Dev_Config;Integrated Security=True;Enlist=False;Connect Timeout=15", building a SqlDataReader.
[7132]

After seeing the message, it was clear that the app was first trying to connect to the config db, then it would connect to the site/library objects.

Sort SPFileCollection by Created Date

Yes, this could be done with a CAML query, but I wanted to keep it simple.

I need to get items created in ascending order (oldest first).

My solution:

SPFileCollection items = web.GetFolder(sLawsonReports).Files;
//sort the files so we get the oldest first
List<SPFile> sortFiles = items.Cast<SPFile>().OrderBy(file => file.TimeCreated).ToList();

SharePoint Workflow Not Starting

For one reason or another, SharePoint Designer Workflows are not always starting when an item is added to a library.  This happens with document libraries and InfoPath form libraries.  I’ve seen this happen with SharePoint 2007 and SharePoint 2010.

What I’ve created is a way to identify, monitor, and start workflows.

Create two lists:

Workflow Monitor

Fields:

Site URL, List Name, Workflow Name

Workflow Monitor Logging

Fields:

Site URL, List Name, Workflow Name, List Item ID

All of the field types are the default single line of text.

Workflow Monitor will be populated with the site url, list name, and workflow name of the workflow you want to monitor.

Place the script in a folder on one of your SharePoint server. Then setup a scheduled task to run the script as needed.


<#
 loop though workflow monitor list
 get workflow item
 query associated list by created date between yesterday and today AND workflow field is empty
 if item is returned, start workflow on item.
 log item that was not started
 if there are any errors send email to DL SharePoint
#>

if ((Get-PSSnapin "Microsoft.SharePoint.PowerShell" -ErrorAction SilentlyContinue) -eq $null)
{
    Add-PSSnapin "Microsoft.SharePoint.PowerShell"
}

$cSite = Get-SPWeb "http://sharepointed.com"
$cList = $cSite.Lists["Workflow Monitor"]
$cListLog = $cSite.Lists["Workflow Monitor Logging"]
$errorCount = 0
$errorString = ""

foreach($config in $cList.Items)
{
	try
	{
		$fSite = Get-SPWeb $config["Site URL"].ToString()
		$wfManager = $fSite.Site.WorkFlowManager
		$fList = $fSite.Lists[$config["List Name"].ToString()]
		$fWFfield = $fList.Fields[$config["Workflow Name"].ToString()].InternalName

		#Get the list workflow
		$wfAssoc = $fList.WorkflowAssociations.GetAssociationByName($config["Workflow Name"].ToString(),"en-US")
		$wfData = $wfAssoc.AssociationData

		$sQuery = New-Object Microsoft.SharePoint.SPQuery

		#Get all item that were created in the past day and a workflow has not ran.
		$caml = '<Where><And><IsNull><FieldRef Name="' + $fWFfield + '" /></IsNull><Geq><FieldRef Name="Created" /><Value Type="DateTime"><Today OffsetDays="-1" /></Value></Geq></And></Where>'
		$sQuery.Query = $caml
		$fItems = $fList.GetItems($sQuery)

		foreach($lItem in $fItems)
		{
			#Start workflow
			$wf = $wfManager.StartWorkFlow($lItem,$wfAssoc,$wfData,$true)

			#Create Log entry
			$newLogItem = $cListLog.Items.Add()
			$newLogItem["Site URL"] = $config["Site URL"]
			$newLogItem["List Name"] = $config["List Name"]
			$newLogItem["List Item ID"] = $lItem["ID"]
			$newLogItem["Workflow Name"] = $config["Workflow Name"]
			$newLogItem.Update()
		}
	}
	Catch
	{
		#string.format
		$errorMessage = $_.Exception.Message.ToString()
		$errorString += $config["ID"].ToString() + " " + $errorMessage + " --- "
		$errorCount++
	}
}

#If there are any errors send email
if($errorCount -gt 0)
{
	$errorString = $errorString.TrimEnd(" --- ")

	$emailSubject = "Workflow Montior Script Error"
	$emailBody = "Error running the Workflow Monitor script. <br><br> <b>Error: </b>"
	$emailBody += "$errorString <br><br>"
	$emailBody += "<a href=$cList.URL.ToString()>Workflow Monitor List </a>"
	$emailsmtpServer = "mail.doman.net"
	$emailTo = "you@sharepointed.com"
	$emailFrom = "alerts@sharepointed.com"

	Send-MailMessage -From $emailFrom -To $emailTo -Subject $emailSubject -BodyAsHtml $emailBody -SmtpServer $emailsmtpServer
}

This script will inventory your entire farm and output workflows that have failed to start int the past 59 days. *You can adjust the 59 day setting, but my farm is setup to truncate workflow history every 60 days.*


$contentWebAppServices = (Get-SPFarm).services |
? {$_.typename -eq "Microsoft SharePoint Foundation Web Application"}

$stringBuilder = New-Object System.Text.StringBuilder
$list = New-Object System.Collections.Generic.List[System.String]
$counter = 0

foreach($webApp in $contentWebAppServices.WebApplications)
{
	$webApp = Get-SPWebApplication $webApp.Url

	if($webApp -ne $null)
	{
		foreach($siteColl in $webApp.Sites)
		{
			if($siteColl -ne $null)
			{
				foreach($subWeb in $siteColl.AllWebs)
				{
					if($subWeb -ne $null)
					{
						foreach($list in $subWeb.Lists)
						{
							foreach($wf in $list.WorkflowAssociations)
							{
								if ($wf.Name -notlike "*Previous Version*")
								{
									$subWeb.Site.WorkflowManager
									$wfManager = $subWeb.Site.WorkFlowManager
									$fWFfield = $list.Fields[$wf.Name.ToString()].InternalName

									#Get the list workflow
									$wfAssoc = $list.WorkflowAssociations.GetAssociationByName($wf.Name,"en-US")
									$wfData = $wfAssoc.AssociationData

									if($wfAssoc.AutoStartCreate -eq $true)
									{
										$counter++

										$sQuery = New-Object Microsoft.SharePoint.SPQuery

										#Get all item that were created in the past day and a workflow has not ran.
										$caml = '<Where><And><IsNull><FieldRef Name="' + $fWFfield + '" /></IsNull><Geq><FieldRef Name="Created" /><Value Type="DateTime"><Today OffsetDays="-59" /></Value></Geq></And></Where>'
										$sQuery.Query = $caml
										$fItems = $list.GetItems($sQuery)

										$null = $stringBuilder.Append($subWeb.URL)
										$null = $stringBuilder.Append(",")
										$null = $stringBuilder.Append($list.Title)
										$null = $stringBuilder.Append(",")
										$null = $stringBuilder.Append($wf.Name.ToString())
										$null = $stringBuilder.Append("`r`n")

									}
								}
							}

						}

						$subWeb.Dispose()
					}
				}
				$siteColl.Dispose()
			}
		}
	}
}

if($counter -gt 0)
{
	out-file -filepath C:\WorkflowOutput.csv -inputobject $stringBuilder.ToString()
}

Document ID Service and Migrating Documents

You are using the Document ID Service in SharePoint and you want to move your documents to another location.  For whatever reason, you notice when you move the documents that your document id’s are lost or reset.  This can be real bad if other systems outside of SharePoint leverage the document id to locate documents in SharePoint.

Here are the steps I used to get around this.
Move the documents from location A to B, keeping the original documents in A.
Run a crawl.
Execute the script below (input your own values for the site and libraries).
Remove / delete the documents from location A. For safe measures, also empty the recycle bin, both at the site and site collection level.
Run another crawl.
Trigger the Document Id Settings to update.

What the script is doing:
Get all the documents in the Shared Documents library of site A.
Loop through the documents.
Locate the document by name in the Shared Documents library of site B.
Update the Document ID of the item.

Things you could improve on:
Get all the documents in site A and output the Name and Document ID to a csv file.
– Then process the csv file with the script.
Add logging.
– Output your pass / fail items to csv file.
Expand the search to query a site.
– Then update the returned item.

if ((Get-PSSnapin "Microsoft.SharePoint.PowerShell" -ErrorAction SilentlyContinue) -eq $null)
{
    Add-PSSnapin "Microsoft.SharePoint.PowerShell"
}

$sSite = Get-SPWeb "http://sharepoint.net/sites/A"
$sList = $sSite.lists["Shared Documents"]

$dSite = Get-SPWeb "http://sharepoint.net/sites/B"
$dList = $dSite.lists["Shared Documents"]

$sQuery = New-Object Microsoft.SharePoint.SPQuery
$sQuery.ViewAttributes = "Scope='Recursive'"
$sQuery.RowLimit = 2000
$sQuery.Query = '<Where><Gt><FieldRef Name="ID" /><Value Type="Counter">0</Value></Gt></Where>'

do
{
	$sItems = $sList.GetItems($sQuery)
	$sQuery.ListItemCollectionPosition = $sItems.ListItemCollectionPosition
	foreach($sI in $sItems)
	{
		$docName = $sI["Name"].ToString()
		Write-Host $docName

		$dQuery = New-Object Microsoft.SharePoint.SPQuery
		$dQuery.ViewAttributes = "Scope='Recursive'"
		$dQuery.RowLimit = 2000
		$dQuery.Query = '<Where><Eq><FieldRef Name="FileLeafRef"/><Value Type="File">' + $docName + '</Value></Eq></Where>'

		do
		{
			$dItems = $dList.GetItems($dQuery)
			$dQuery.ListItemCollectionPosition = $dItems.ListItemCollectionPosition
			foreach($dI in $dItems)
			{
				try
				{
					$dI["Document ID Value"] = $sI["Document ID Value"]
					$dI.Update()
					Write-Host $dI["Name"] " has been updated"
				}
				catch
				{
					Write-Host $dI["Name"] " ---- " $_.Exception.Message
				}
			}
		}
		while ($dQuery.ListItemCollectionPosition -ne $null)
	}
}
while ($sQuery.ListItemCollectionPosition -ne $null)

Find all Lists and Libraries Where InfoPath is Used

Recently had the need to find and update most every InfoPath form in a production farm. This, mixed with the future demise of InfoPath, prompted the need to find or write a script. The below script will traverse every list and library in a given web app. The script can be easily modified to include every web app in a farm.

if ((Get-PSSnapin "Microsoft.SharePoint.PowerShell" -ErrorAction SilentlyContinue) -eq $null)
{
                Add-PSSnapin "Microsoft.SharePoint.PowerShell"
}

$fileName = "C:\xsn-" + $(Get-Date -Format "yyyyMMddHHmmss") + ".csv"

$webApp = Get-SPWebApplication "http://webApp.sharepointed.com"
"Title `t URL `t Type" | out-file $fileName

$(foreach($siteColl in $webApp.Sites)
{
                foreach($web in $siteColl.AllWebs)
                {
                foreach($list in $web.Lists) {

                                if ($list.BaseType -eq "DocumentLibrary" -and $list.BaseTemplate -eq "XMLForm"){
                                                "$($list.title) `t $($list.parentweb.url)$($list.DefaultViewUrl) `t Library" | out-file $fileName -Append


                                }elseif ($list.ContentTypes[0].ResourceFolder.Properties["_ipfs_infopathenabled"]){

                                                "$($list.title) `t $($list.ParentWeb.URL)$($list.DefaultViewUrl) `t List" | out-file $fileName -Append

                                                }
												else{
												$check = 0
								foreach($c in $list.ContentTypes) {
												if($c.DocumentTemplateUrl.ToString().EndsWith("xsn") -eq $true)
												{
													$check++
												}
												}
												if($check -gt 0)
												{
													"$($list.title) `t $($list.ParentWeb.URL)$($list.DefaultViewUrl) `t List" | out-file $fileName -Append
												}
												}
												}}})
